Features
Efficient Two-Stage Design

The two-stage design efficiently handles wet, heavy snow. A low-speed auger collects the snow, moving it to the center, where a high-speed impeller blows it out of the discharge chute. This allows snow removal over greater distances and handles volumes of up to 100 lb (45.4 kg) per minute.
Heavy-Duty Cast-Iron Drive

A heavy-duty cast-iron helical gearcase drives the blower impeller, maximizing engine horsepower for excellent snow throwing capacity and distance. The telescoping drive shaft ensures easy attachment, making it efficient and reliable in various snow conditions.
Heavy-Duty Front 3-Point Hitch

The heavy-duty snow blower mounts using a robust front 3-point hitch, allowing quick attachment of implements. This design offers added strength and longer life, consistent levelness, improved maneuverability, and faster implement changes with a shared A-frame quick attach system.
Scraper Blade
| Type | Reversible and replaceable |
Spout
| Diameter | 7.25 in. |
| Diameter | 184 mm |
| Rotation | 200 degree (angle) |
| Rotation Control | Hydraulic remote control |
Dimensions
| Overall Width | 49.6 in. |
| Overall Width | 1260 mm |
| Clearing Width | 47 in. |
| Clearing Width | 1194 mm |
| Height Of Opening | 23 in. |
| Height Of Opening | 584 mm |
| Housing Thickness | 0.075 in. |
| Housing Thickness | 1.9 mm |
| Side Panel Thickness | 0.25 in. |
| Side Panel Thickness | 6.35 mm |
| Height To Top Of Chute Deflector | 51.8 in. |
| Height To Top Of Chute Deflector | 1315 mm |
| Housing Depth | 17 in. |
| Housing Depth | 432 mm |
Auger
| Auger Diameter | 16 in. |
| Auger Diameter | 406 mm |
| Auger Speed | 189-199 rpm |
| Auger Drive | Splined-coupler power take-off (PTO) shaft to helical gearcase |
| Auger Drive Gearbox | Cast-iron worm gearcase with 1.25-in. (32-mm) output shafts |
| Auger Protection | Shear bolt for each auger half, four shell-mounted extra shear bolts |
Weight
| Approximate Weight | 390 lb. |
| Approximate Weight | 177 kg |
Setup Time
| Attaching Time | 4 min. |
| Removal Time | 3 min. |
Lift System
| Type | Hydraulic cylinder on front 3-point hitch |
Blower
| Speed | 898-943 rpm |
| Blower Fan Material | Welded steel |
| Blower Fan Size | 3.94 x 16 in. |
| Blower Fan Size | 100 x 406 mm |
| Bearing | Sealed ball bearings |
