Features
Designed for Improved Operator Comfort
This backhoe’s operator station enhances comfort with a high-back seat, non-slip grips, and accessible controls. The design includes a strong stance for safe mounting and convenient boom and swing locks accessible from the operator's seat.
Convenient and Easy Operation
Designed with practicality in mind, this backhoe offers a pivoting seat for debris prevention, a low-profile console for unobstructed views, and streamlined two-lever control for easier handling, along with a cushioned boom cylinder for smoother operation.
Backhoe Performance
Engineered for high-quality digging performance by matching the tractor's hydraulic flow and system pressure with the backhoe. Features include valve spools for smooth operation, a durable sub-frame, and optimized bucket design for increased productivity.
Dimensions
| Digging Depth | 2.13 m |
| Digging Depth | 7 ft |
| Loading Height (Bucket at 60 Degrees) | 1.74 m |
| Loading Height (Bucket at 60 Degrees) | 6.08 ft |
| Reach From Center Line of Swing Pivot | 3 m |
| Reach From Center Line of Swing Pivot | 9.75 ft |
| Transport Height | 1.92 m |
| Transport Height | 6.25 ft |
| Loading Reach (Bucket at 60 Degrees) | 1.13 m |
| Loading Reach (Bucket at 60 Degrees) | 3.58 ft |
| Transport Overhang | 1.1 m |
| Transport Overhang | 3.5 ft |
| Undercut | 43 cm |
| Undercut | 17 in. |
| Stabilizer Spread Width - Up | 1.47 m |
| Stabilizer Spread Width - Up | 4.83 ft |
| Stabilizer Spread Width - Down | 1.92 m |
| Stabilizer Spread Width - Down | 6.58 ft |
Backhoe
| Swing Arc | 150 degree (angle) |
| Bucket Rotation | 180 degree (angle) |
| Boom Lift Capacity | 116 kg |
| Boom Lift Capacity | 256 lb. |
| SAE Dipperstick Digging Force | 6681 N |
| SAE Dipperstick Digging Force | 1502 lbf |
| SAE Bucket Digging Force | 11005 N |
| SAE Bucket Digging Force | 2474 lbf |
| Bucket Control Main Relief Valve Pressure | 16350.6 kPa |
| Bucket Control Main Relief Valve Pressure | 2370 psi |
Bucket
| Bucket Widths | 20.3, 30.5, 40.6 cm |
| Bucket Widths | 8, 12, 16 in. |
| SAE Struck Capacity | 20.3 cm (8 in.): 0.011 m³ (0.42 cu ft); 30.5 cm (12 in.): 0.019 m³ (0.66 cu ft); 40.6 cm (16 in.): 0.025 m³ (0.9 cu ft) |
| Heaped Capacity | 20.3 cm (8 in.): 0.013 m³ (0.46 cu ft); 30.5 cm (12 in.): 0.022 m³ (0.76 cu ft); 40.6 cm (16 in.): 0.03 m³ (1.06 cu ft) |
| Shipping Weight | 20.3 cm (8 in.): 40 lb (18.1 kg); 30.5 cm (12 in.): 50 lb (22.7 kg); 40.6 cm (16 in.): 60 lb (27.2 kg) |
Weight
| Weight With 0.4-m (16-in.) Bucket | 350 kg |
| Weight With 0.4-m (16-in.) Bucket | 773 lb. |
