Features
Mid-Mower Lift System
The mid-mower lift system features automatic front hanger connection, a self-adjusting PTO shaft, and a locking latch for stability. It offers three lift options: mechanical (linked to rear implements), hydraulic (independent of rear), and independent hydraulic (full control via joystick button).
Mower Height Adjustment
The height-of-cut (HOC) adjustment is located on the tractor and can easily be adjusted with the turn of the knob. To install/remove mower deck, the HOC adjustment knob must be set in the install position.
Compatible with Front/Rear Implements
The High-Capacity AutoConnect™ deck is compatible with rear 3-point hitch attachments, backhoes, and loaders. The operator can keep these extra implements attached while mowing.
Dimensions
| Cutting Width | 54 in. |
| Cutting Width | 137 cm |
| Overall Width - Deflector Up | 6 in. |
| Overall Width - Deflector Up | 152 cm |
| Overall Width - Deflector Down | 68.5 in. |
| Overall Width - Deflector Down | 174 cm |
| Cutting Height | 1 - 4 in. |
| Cutting Height | 2.54 - 10.16 cm |
| Deck Thickness | 0.1345 in. |
| Deck Thickness | 3.416 mm |
| Deck Thickness | 10 gauge |
Blades
| Number Of Blades | 3 |
| Length | 19.1 in. |
| Length | 48.5 cm |
| Thickness | 0.25 in. |
| Thickness | 0.63 cm |
| Blade Tip Speed (At 2600 rpm) | 16751 fpm |
| Blade Tip Speed (At 2600 rpm) | 5106 m/min |
Weight
| Approximate Weight | 197 lb. |
| Approximate Weight | 89 kg |
Compatibility
| Compatible Models | 1023E, 1025R, and 1026R |
Wheels
| Front Gauge Wheel Size | 5 in. / 12.7 cm |
| Rear Gauge Wheel Size | 5 in. / 12.7 cm |
Spindles
| Diameter | 0.787 in. |
| Diameter | 2 cm |
Mulching
