Features
Breakaway Feature
The breakaway feature includes two large coil springs that help the blade edge retract when encountering a solid object. This reduces the operational shock experienced by the driver and minimizes the risk of blade damage. A locking pin keeps the blade secured in the desired position.
Heavy-Duty Construction
A reinforcing angle behind the blade's front edge ensures durability. The blade has a replaceable cutting edge that forms a continuous curve, rolling material rather than pushing it, which enhances capacity and extends the blade's life.
Adjustable Skid Shoes
Adjustable skid shoes offer eight different height settings, enabling operators to choose the appropriate blading height for various tasks. This adjustability simplifies achieving uniform grading and prolongs skid shoes' utility. Optional heavy-duty skid shoes available for purchase.
Additional Information
| Removal Time | 5 min. |
| Attaching Time | 5 min. |
Angling Positions
| Right And Left | 15 degree (angle) / 30 degree (angle) |
| Number Of Positions | 5 |
Cutting Width
| Blade Straight | 122 cm |
| Blade Straight | 48 in. |
| Blade Angled | 47 in. |
| Blade Angled | 119 cm |
Blade Skid Shoes
Material Thickness
| Replaceable Scraper Edge | 0.188 in. |
| Replaceable Scraper Edge | 4.76 mm |
| Blade | 3.05 mm |
| Blade | 0.12 in. |
Weight
| Approximate Weight | 110 lb. |
| Approximate Weight | 50 kg |
Blade Float
| Type | Built into tractor linkage |
Range Of Lift
| Garden Tractors - Above Ground Level | 13 cm |
| Garden Tractors - Above Ground Level | 5 in. |
| Garden Tractors - Below Ground Level | 7.6 cm |
| Garden Tractors - Below Ground Level | 3 in. |
Dimensions
| Overall Length | 218 cm |
| Overall Length | 17 in. |
| Overall Height | 86 in. |
| Overall Height | 43 cm |
Blade Trip
| Type | Spring-trip with lock |
