Features
Adjustable Skid Shoes
Adjustable skid shoes allow the snow blower cutting edge to glide smoothly over gravel drives and uneven surfaces. Stamped from heavy-gauge steel, these shoes are held securely in place by bolts and can be adjusted for different surface conditions, enhancing durability and usability.
Two-Stage Design
The 44-in. (112-cm) snow blower features a two-stage design with a cast-iron gearbox and shear bolts, effectively handling deep snow conditions. A low-speed auger picks up snow and moves it to the high-speed rotor for discharge, ensuring consistent snow placement with high velocity.
Spout and Deflector
Equipped with a high-density polyethylene spout and deflector, this system resists snow buildup and won't dent or rust. Operator controls allow for easy adjustment and rotation up to 200 degrees, providing smooth and clog-free operation even in cold weather.
Auger
| Diameter | 12 in. |
| Diameter | 30.5 cm |
| Auger Drive Gearbox | Cast-iron worm-drive gearbox |
| Protection | Shear bolt for each auger half |
| Drift Knife | Optional for both sides of housing |
| Drive | In-line V-belt |
| Bearing | 0.75 in. |
| Bearing | 19 mm |
Scraper Blade
| Type | Scraper edge: replaceable |
Spout
| Diameter | 15.2 cm |
| Diameter | 6 in. |
| Rotation Control | Manual remote handle |
| Rotation | 100 degree (angle) |
Dimensions
| Width - Clearing | 44 in. |
| Width - Overall | 112 cm |
| Width - Overall | 44 in. |
Lift System
| Lift Height | 4 in. |
| Lift Height | 102 mm |
| Type | Spring-assisted foot lift or hydraulic lift X300 Series Tractors |
Weight
| Approximate Weight | 180 lb. |
| Approximate Weight | 81.6 kg |
Blower
| Blower Fan Material | Ultra high molecular weight (UHMW) polyethylene |
| Blower Fan Size | 4.75x14 in. |
| Blower Fan Size | 12.1x35.6 cm |
| Blower Fan Drive | Cast-iron right-angle gearbox |
Setup Time
| Attaching Time | No tools required: 5 minutes |
