Features
Automatic Mast Latch for Easy Removal
The loader is equipped with an automatic mast latch system, simplifying the process of attaching and detaching the loader. This system allows for easy parking and enhances operational uptime by enabling the loader to latch with minimal effort.
Concealed Oil Lines for Protection
The R Series Loaders are designed to route the oil lines and hydraulic lines through the boom arm and the torque tube. This internal routing ensures better protection of the lines from external damage and improves the overall appearance of the loader.
Single-Point Hydraulic Connection
The R Series Loaders feature a single-point hydraulic connection that streamlines the process of attaching and detaching the loader. This system combines all hydraulic and electrical connections into one location for efficient installation with a simple handle pull.
Tractor
| Wheelbase | 110 in. |
| Wheelbase | 2800 mm |
| Rear Tire | SRI975 650/85R38 |
| Pump Capacity | 114 L/min |
| Pump Capacity | 30.1 gpm |
| Rated Pressure | 200 bar |
| Model | 6R 180, 6R 200, 6R 220, 6R 240 |
| Rated Pressure | 2900 psi |
| Front Axle Configuration | MFWD |
| Front Tire | SRI750 480/70R34 |
Loader
| Boom Breakout Force - Measured At Pivot (Y) | 2974 kg |
| Boom Breakout Force - Measured At 800 mm Ahead Of Pivot (Z) | 2266 kg |
| At Maximum Height (VV) | 6263 lb. |
| Lift Capacity At 59 in. (1500 mm) - Measured At 800 mm Ahead Of Pivot (X) | 2268 kg |
| Loader Lower | 1.99 seconds |
| Bucket Dump | 2.8 seconds |
| Dump Angle (E) | 51 degree (angle) |
| Maximum Lift Height (A) | 173 in. |
| Bucket Used | Heavy-duty grapple 2150 mm Heavy-duty grapple 85 in. |
| Lift Capacity At Full Height - Measured At Pivot (U) | 5883 lb. |
| At Maximum Height (VV) | 2841 kg |
| Base Weight | 1674.3 kg |
| Overall Length (I+F) | 230 in. |
| Maximum Lift Height (A) | 4405 mm |
| Dump Angle, Ground | 132 degree (angle) |
| Lift Capacity At Full Height - Measured At Pivot (U) | 2668 kg |
| At Full Height - Bucket Level (B) | 4069 mm |
| Bucket Weight | 721 lb. |
| Loader Raise | 2.89 seconds |
| Digging Depth (H) | 7 in. |
| Overall Length (I+F) | 5854 mm |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 4794 kg |
| Boom Breakout Force - Measured At Pivot (Y) | 6557 lb. |
| Rollback Angle (G) | 56 degree (angle) |
| Boom Breakout Force - Measured At 800 mm Ahead Of Pivot (Z) | 4996 lb. |
| Lift Capacity At 59 in. (1500 mm) - Measured At 800 mm Ahead Of Pivot (X) | 5000 lb. |
| Leveling Configuration | Non-Self Leveling (NSL) |
| At Full Height - Bucket Level (B) | 160 in. |
| Bucket Weight | 327 kg |
| Digging Depth (H) | 185 mm |
| Bucket Rollback | 1.91 seconds |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 10569 lb. |
