Features
Single-Point Hydraulic Connection Saves Time
A single-point hydraulic connection saves operators time when attaching or detaching the loader. This system also includes connections for electrical needs and a hydraulic lockout valve, allowing for fast installation via a simple handle pull.
Boom Lockout for Easy Service
A hydraulic shut-off valve prevents the loader from lowering unexpectedly, enabling safe maintenance under the boom.
Concealed Oil Lines for Protection
Wider tractor hoods have reduced space for traditional oil line routing along the boom, increasing the risk of damage. To address this, the oil lines are now routed through the boom arm and torque tube, enhancing protection and improving the loader’s appearance.
Tractor
| Model | 6135E |
| Front Tire | 14.9R24 |
| Rear Tire | 18.4R38 |
| Front Axle Configuration | MFWD |
| Wheelbase | 2380 mm |
| Wheelbase | 94 in. |
| Pump Capacity | 75.7 L/min |
| Pump Capacity | 20 gpm |
| Rated Pressure | 195 bar |
| Rated Pressure | 2828 psi |
Loader
| Base Weight | 1028.2 kg |
| Leveling Configuration | Mechanical Self-Leveling (MSL) |
| Bucket Used | Materials - 1850 mm / 73 in. |
| Bucket Weight | 246 kg |
| Bucket Weight | 542 lb. |
| Lift Capacity At Full Height - Measured At Pivot (U) | 1373 kg |
| Lift Capacity At Full Height - Measured At Pivot (U) | 3027 lb. |
| Lift Capacity At Full Height - Measured At 800 mm Ahead Of Pivot | 1481 kg |
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 2015 kg |
| Lift Capacity At 59 in. (1500 mm) - Measured At 800 mm Ahead Of Pivot (X) | 1931 kg |
| Boom Breakout Force - Measured At Pivot (Y) | 2671 kg |
| Boom Breakout Force - Measured At 800 mm Ahead Of Pivot (Z) | 2325 kg |
| At Maximum Height (VV) | 1636 kg |
| At 59-in. (1500 mm) Lift Height (XX) | 2986 kg |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 3046 kg |
| Maximum Lift Height (A) | 3578 mm |
| Maximum Lift Height (A) | 141 in. |
| At Full Height - Bucket Level (B) | 3383 mm |
| At Full Height - Bucket Level (B) | 133 in. |
| Clearance At Full Height - Bucket Dumped | 2538 mm |
| Clearance At Full Height - Bucket Dumped | 100 in. |
| Overall Length (I+F) | 4800 mm |
| Overall Length (I+F) | 190 in. |
| Digging Depth (H) | 47 mm |
| Digging Depth (H) | 1.9 in. |
| Reach - At Maximum Height (D) | 1011 mm |
| Reach - At Maximum Height (D) | 39.8 in. |
| Reach - At Ground Level - Bucket Level | 2426 mm |
| Reach - At Ground Level - Bucket Level | 95.5 in. |
| Dump Angle (E) | -74 degree (angle) |
| Rollback Angle (G) | 42 degree (angle) |
| Dump Angle, Ground | -96 degree (angle) |
| Loader Raise | 3.4 seconds |
| Loader Lower | 2.5 seconds |
| Bucket Dump | 2.1 seconds |
| Bucket Rollback | 2.1 seconds |
