Features
Quick-Change Attachment Carrier
The quick-change attachment carrier allows for fast, easy removal and mounting of attachments without tools.
End-of-Pin Lubrication
Grease fittings accessible from the loader’s side make maintenance easier.
Parking Stand Kit
The parking stand kit enables quick, tool-free removal of the loader from the tractor. It includes parking stands, handled pins, hydraulic hoses, quick-couplers, and mounting hardware.
Tractor
| Model | 4044M, 4049M, 4052M, 4066M and OOS: 4044R, 4049R, 4052R, 4066R |
| Front Tire | 25x10-16.5 4PR R4 |
| Rear Tire | 16.9-24 4PR |
| Wheelbase | 1850 mm |
| Wheelbase | 73 in. |
| Pump Capacity | 10.2 gpm |
| Rated Pressure | 2500 psi |
Loader
| Base Weight | 150.99 kg |
| Bucket Used | Materials |
| Bucket Weight | 108 kg |
| Bucket Weight | 238 lb. |
| Lift Capacity At Full Height - Measured At Pivot (U) | 1087 kg |
| Lift Capacity At Full Height - Measured At Pivot (U) | 2396 lb. |
| Lift Capacity at Full Height - Measured at 500 mm Ahead of Pivot | 800 kg |
| Lift Capacity at Full Height - Measured at 500 mm Ahead of Pivot | 1764 lb. |
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 1307 kg |
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 2881 lb. |
| Lift Capacity at 59 in (1500 mm) - Measured at 500 mm Ahead of Pivot | 1043 kg |
| Lift Capacity at 59 in. (1500 mm) - Measured at 500 mm Ahead of Pivot | 2299 lb. |
| Boom Breakout Force - Measured At Pivot (Y) | 1743.7 kg |
| Boom Breakout Force - Measured At Pivot (Y) | 3853 lb. |
| Boom Breakout Force - Measured at 500 mm Ahead of Pivot | 1315.4 kg |
| Boom Breakout Force - Measured at 500 mm Ahead of Pivot | 2902 lb. |
| At Maximum Height (VV) | 1866.1 kg |
| At Maximum Height (VV) | 4112 lb. |
| At 59-in. (1500 mm) Lift Height (XX) | 2355.1 kg |
| At 59-in. (1500 mm) Lift Height (XX) | 5191 lb. |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 3487 kg |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 1580.6 lb. |
| Maximum Lift Height (A) | 2850 mm |
| Maximum Lift Height (A) | 112.1 in. |
| At Full Height - Bucket Level (B) | 2646 mm |
| At Full Height - Bucket Level (B) | 104.1 in. |
| Clearance At Full Height - Bucket Dumped | 2298 mm |
| Clearance At Full Height - Bucket Dumped | 90.4 in. |
| Overall Length (I+F) | 3522 mm |
| Overall Length (I+F) | 138 in. |
| Overall Height In Carry Position | 1500 mm |
| Overall Height In Carry Position | 59 in. |
| Digging Depth (H) | -146 mm |
| Digging Depth (H) | 5.7 in. |
| Reach - At Maximum Height (D) | 705 mm |
| Reach - At Maximum Height (D) | 27.7 in. |
| Reach - At Ground Level - Bucket Level | 1672 mm |
| Reach - At Ground Level - Bucket Level | 65.8 in. |
| Dump Angle (E) | 42 degree (angle) |
| Rollback Angle (G) | 28.6 degree (angle) |
| Dump Angle, Ground | 128.2 degree (angle) |
| Loader Raise | 4.26 seconds |
| Loader Lower | 3.13 seconds |
| Bucket Dump | 3.14 seconds |
| Bucket Rollback | 2.42 seconds |
