Features
End-of-Pin Lubrication
Grease fittings accessible from the loader’s side make maintenance easier.
Quick-Change Attachment Carrier
The quick-change attachment carrier allows for fast, easy removal and mounting of attachments without tools.
Quik-Park™ Loader Mounting System
This system allows for the quick removal and reattachment of the loader without needing any tools. The integrated parking stand lowers by joystick action, transitioning the loader swiftly to a parked position once unlocked, enhancing operational convenience.
Tractor
| Model | 4105 |
| Front Tire | 10-16.5 6PR R4T1 |
| Rear Tire | 17.52-24 8PR R4T1 |
| Wheelbase | 1727 mm |
| Wheelbase | 68 in. |
| Pump Capacity | 5.7 gpm |
| Rated Pressure | 2500 psi |
Loader
| Base Weight | 281.09 kg |
| Bucket Used | Materials |
| Bucket Weight | 93.8 kg |
| Bucket Weight | 207 lb. |
| Lift Capacity At Full Height - Measured At Pivot (U) | 633 kg |
| Lift Capacity At Full Height - Measured At Pivot (U) | 1393 lb. |
| Lift Capacity at Full Height - Measured at 500 mm Ahead of Pivot | 457 kg |
| Lift Capacity at Full Height - Measured at 500 mm Ahead of Pivot | 1005 lb. |
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 959 kg |
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 2109 lb. |
| Lift Capacity at 59 in (1500 mm) - Measured at 500 mm Ahead of Pivot | 745 kg |
| Lift Capacity at 59 in. (1500 mm) - Measured at 500 mm Ahead of Pivot | 1639 lb. |
| Boom Breakout Force - Measured At Pivot (Y) | 1710 kg |
| Boom Breakout Force - Measured At Pivot (Y) | 3769 lb. |
| Boom Breakout Force - Measured at 500 mm Ahead of Pivot | 1209 kg |
| Boom Breakout Force - Measured at 500 mm Ahead of Pivot | 2665 lb. |
| At Maximum Height (VV) | 822 kg |
| At Maximum Height (VV) | 1819 lb. |
| At 59-in. (1500 mm) Lift Height (XX) | 1397 kg |
| At 59-in. (1500 mm) Lift Height (XX) | 3079 lb. |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 1335.4 kg |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 2944 lb. |
| Maximum Lift Height (A) | 2616 mm |
| Maximum Lift Height (A) | 103.3 in. |
| At Full Height - Bucket Level (B) | 2411 mm |
| At Full Height - Bucket Level (B) | 94.9 in. |
| Clearance At Full Height - Bucket Dumped | 2003 mm |
| Clearance At Full Height - Bucket Dumped | 78.8 in. |
| Overall Length (I+F) | 3218 mm |
| Overall Length (I+F) | 127 in. |
| Digging Depth (H) | 121 mm |
| Digging Depth (H) | 4.76 in. |
| Reach - At Maximum Height (D) | 766 mm |
| Reach - At Maximum Height (D) | 30.1 in. |
| Reach - At Ground Level - Bucket Level | 1491 mm |
| Reach - At Ground Level - Bucket Level | 50.7 in. |
| Dump Angle (E) | 49.3 degree (angle) |
| Rollback Angle (G) | 23.8 degree (angle) |
| Dump Angle, Ground | 138 degree (angle) |
| Loader Raise | 3.6 seconds |
| Loader Lower | 2.1 seconds |
| Bucket Dump | 3 seconds |
| Bucket Rollback | 1.8 seconds |
