Features
End-of-Pin Lubrication
Grease fittings accessible from the loader’s side make maintenance easier.
Quick-Change Attachment Carrier
The quick-change attachment carrier allows for fast, easy removal and mounting of attachments without tools.
Optional Field-Installed Mechanical Self-Leveling Loader (MSL)
The MSL loader for 1, 2, 3D, and 3E Tractors enables operators of all experience levels to handle loads with greater ease and confidence, thanks to features like consistent implement positioning, increased lift capacity, and reduced material loss.
Tractor
| Model | 3025E, 3032E, 3038E |
| Front Tire | 25x8.50-14 4PR R4 |
| Rear Tire | 15.00-19.5 4PR |
| Wheelbase | 1595 mm |
| Wheelbase | 62.8 in. |
| Pump Capacity | 5.3 gpm |
| Rated Pressure | 2495 psi |
Loader
| Base Weight | 306.4 kg |
| Bucket Used | Materials - 1550 mm |
| Bucket Weight | 93 kg |
| Bucket Weight | 205 lb. |
| Lift Capacity At Full Height - Measured At Pivot (U) | 539 kg |
| Lift Capacity At Full Height - Measured At Pivot (U) | 1186 lb. |
| Lift Capacity at Full Height - Measured at 500 mm Ahead of Pivot | 384 kg |
| Lift Capacity at Full Height - Measured at 500 mm Ahead of Pivot | 845 lb. |
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 588 kg |
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 1294 lb. |
| Lift Capacity at 59 in (1500 mm) - Measured at 500 mm Ahead of Pivot | 444 kg |
| Lift Capacity at 59 in. (1500 mm) - Measured at 500 mm Ahead of Pivot | 977 lb. |
| Boom Breakout Force - Measured At Pivot (Y) | 760 kg |
| Boom Breakout Force - Measured At Pivot (Y) | 1704 lb. |
| Boom Breakout Force - Measured at 500 mm Ahead of Pivot | 537 kg |
| Boom Breakout Force - Measured at 500 mm Ahead of Pivot | 1204 lb. |
| At Maximum Height (VV) | 639 kg |
| At Maximum Height (VV) | 1433 lb. |
| At 59-in. (1500 mm) Lift Height (XX) | 809 kg |
| At 59-in. (1500 mm) Lift Height (XX) | 1814 lb. |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 634 kg |
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 1422 lb. |
| Maximum Lift Height (A) | 2140 mm |
| Maximum Lift Height (A) | 84 in. |
| At Full Height - Bucket Level (B) | 1979 mm |
| At Full Height - Bucket Level (B) | 78 in. |
| Clearance At Full Height - Bucket Dumped | 1596 mm |
| Clearance At Full Height - Bucket Dumped | 63 in. |
| Overall Length (I+F) | 2900 mm |
| Overall Length (I+F) | 114 in. |
| Overall Height In Carry Position | 161 mm |
| Overall Height In Carry Position | 6 in. |
| Digging Depth (H) | 131 mm |
| Digging Depth (H) | 5 in. |
| Reach - At Maximum Height (D) | 603 mm |
| Reach - At Maximum Height (D) | 24 in. |
| Reach - At Ground Level - Bucket Level | 1369 mm |
| Reach - At Ground Level - Bucket Level | 54 in. |
| Dump Angle (E) | 43.8 degree (angle) |
| Rollback Angle (G) | 31.4 degree (angle) |
| Dump Angle, Ground | 122 degree (angle) |
| Loader Raise | 3.31 seconds |
| Loader Lower | 2.75 seconds |
| Bucket Dump | 1.75 seconds |
| Bucket Rollback | 1.88 seconds |
